Overview : P8Z77-V DELUXE
* PCIe 3.0 speed is supported by Intel® 3rd generation Core™ processors.
| P8Z77-V DELUXE | P8Z77-V PRO | P8Z77-V | P8Z77-V LE PLUS | P8Z77-V LE | P8Z77-V LK | P8Z77-V LX | P8Z77-M PRO | P8Z77-M | P8Z77-I DELUXE | |
| CPU Socket | Intel® Socket 1155 for 3rd/2nd Generation Processors | |||||||||
| Chipset | Intel® Z77 Express Chipset | |||||||||
| Memory | DDR3 2800(O.C.) MHz | DDR3 2600(O.C.) MHz | DDR3 2400(O.C.) MHz | |||||||
| Digital CPU Power Design | Dual Intelligent Processors 3 - SMART DIGI+ Power Control | DIGI+ VRM Digital Power Design | ||||||||
| Digital 20-Phase Power (16-Phase for CPU & 4-Phase for iGPU) |
Digital 16-Phase Power (12-Phase for CPU & 4-Phase for iGPU) |
Digital 12-Phase Power (8-Phase for CPU & 4-Phase for iGPU) |
Digital 8-Phase Power (6-Phase for CPU & 2-Phase for iGPU) |
Digital 8-Phase Power (6-Phase for CPU & 2-Phase for iGPU) |
Digital 4+1 Phase (4-Phase for CPU & 1-Phase for iGPU) |
Digital 4+1 Phase (4-Phase for CPU & 1-Phase for iGPU) |
Digital 8-Phase Power (6-Phase for CPU & 2-Phase for iGPU) |
Digital 5-Phase Power (4-Phase for CPU & 1-Phase for iGPU) |
Digital 10-Phase Power (8 -phase for CPU & 2 -phase for iGPU) |
|
| Digital DRAM Power Design | V | V | V | V | V | N/A | N/A | N/A | N/A | N/A |
| PCIex16 Slots | 2*PCIe 3.0 x16; 1*PCIe 2.0 x16 |
2*PCIe 3.0 x16; 1*PCIe 2.0 x16 |
2*PCIe 3.0 x16; 1*PCIe 2.0 x16 |
2*PCIe 3.0 x16; 1*PCIe 2.0 x16 |
1*PCIe 3.0 x16; 1*PCIe 2.0 x16 |
2*PCIe 3.0 x16; 1*PCIe 2.0 x16 |
1*PCIe 3.0 x16; 1*PCIe 2.0 x16 |
2*PCIe 3.0 x16; 1*PCIe 2.0 x16 |
1*PCIe 3.0 x16; 1*PCIe 2.0 x16 |
1*PCIe 3.0 x16 |
| Multi-GPU | CrossFireX/SLI | CrossFireX/SLI | CrossFireX/SLI | CrossFireX/SLI | CrossFireX | CrossFireX/SLI | CrossFireX | CrossFireX/SLI | CrossFireX | N/A |
| Gb LAN | 2 (Intel/Realtek) | 1 (Intel) | 1 (Intel) | 1 | 1 | 1 | 1 | 1 | 1 | 1 (Intel) |
| Wireless Connection | Wi-Fi 802.11 a/b/g/n Dual band 2.4/5GHz & Bluetooth v4.0 |
Wi-Fi 802.11 b/g/n | N/A | Wi-Fi 802.11 a/b/g/n Dual band 2.4/5GHz & Bluetooth v4.0 |
||||||
| Audio | 8-ch HD, DTS | 8-ch HD, DTS | 8-ch HD, DTS | 8-ch HD | 8-ch HD | 8-ch HD | 8-ch HD | 8-ch HD | 8-ch HD | 8-ch HD, DTS |
| Storage | 4*SATA 6Gb/s 4*SATA 3Gb/s 2*eSATA 6Gb/s |
4*SATA 6Gb/s 4*SATA 3Gb/s 1*eSATA (by bracket) |
4*SATA 6Gb/s 4*SATA 3Gb/s |
4*SATA 6Gb/s (1 is eSATA port) 4*SATA 3Gb/s |
4*SATA 6Gb/s (1 is eSATA port) 4*SATA 3Gb/s |
2*SATA 6Gb/s 4*SATA 3Gb/s |
2*SATA 6Gb/s 4*SATA 3Gb/s |
2*SATA 6Gb/s 4*SATA 3Gb/s 2*eSATA 6Gb/s |
2*SATA 6Gb/s 4*SATA 3Gb/s |
2*SATA 6Gb/s 2*SATA 3Gb/s 2*eSATA 3Gb/s |
| USB 3.0 | 8*USB 3.0 (6 ports at back panel, 2 ports at mid-board) |
8*USB 3.0 (4 ports at back panel, 4 ports at mid-board) |
6*USB 3.0 (4 ports at back panel, 2 ports at mid-board) | 4*USB 3.0
(2 at back panel, 2 at mid-board) |
6*USB 3.0 (4 ports at back panel, 2 ports at mid-board) |
4*USB 3.0 (2 at back panel, 2 at mid-board) |
6*USB 3.0 (4 ports at back panel, 2 ports at mid-board) | |||
| TPU/EPU (with onboard switch) |
V | V | V | V | V | EPU | EPU w/o switch | V | EPU w/o switch | EPU w/o switch |
| ASUS Wi-Fi GO! | V | V | V | N/A | V | |||||
| ASUS Fan Xpert 2 | V | V | V | Fan Xpert+ | Fan Xpert+ | Fan Xpert+ | Fan Xpert+ | Fan Xpert+ | Fan Xpert+ | N/A |
| USB BIOS Flashback | V | V | V | V | V | N/A | N/A | V | V | V |
| Network iControl | V | V | V | V | V | V | V | V | V | V |
| LucidLogix Virtu MVP | V | V | V | V | V | V | V | V | V | V |
